JVC's proprietary 8K e-shift technology reproduces image quality beyond 4K. It works by shifting pixels diagonally 0.5 pixel, quadrupling the picture resolution. Together with three native 4K D-ILA devices, the projector is able to realize 8K image resolution of over 35 million pixels.
The DLA-RS3000 is compatible with HDR 10 for content such as UHD Blu-ray and HLG (Hybrid Log-Gamma) adopted in broadcasting. It is also equipped with a new feature, "Auto Tone Mapping" that automatically adjusts settings based on the mastering information included in HDR content. This feature enables different HDR images to be viewed optimally for specific content.
JVC's new 0.69 inch native 4K D-ILA device delivers the sharpest home theater image available. The 4096 x 2160 device with 3.8µm pixel pitch exceeds 4 times HD resolution— 8.8 million pixels before e-shift. With original vertical orientation technology and a planarization technique that reduces light scattering and diffraction, the device achieves a very high native contrast ratio. The result is smooth, detailed images without visible pixels even on very large screens.
The DLA-RS3000 is equipped with a high resolution 18 element, 16 group all glass lens with an aluminum lens barrel ensuring high resolution to every corner of the screen. Thanks to its 100mm diameter, a wide shift range of +/-100% vertical, +/-43% horizontal is achieved. Five special low dispersion lenses accommodate the different refractive index of Red, Green and Blue suppressing chromatic aberration, color bleeding, and faithfully reproducing 8K resolution.
The DLA-RS3000 incorporates many functions that enhance the color, brightness and contrast performance.
Helps the projector achieve a wide color gamut beyond DCI-P3 as well as BT.709 for exceptionally rich colors.
Optimizes image quality under various installation conditions and also compensates for the changing color balance in long-term projector usage.
Comes from the ultra-high pressure mercury lamp, highly efficient optical engine, luminance of 2,200 lm and narrow pixel gap of the D-ILA device.
This projector is compatible with commercially available anamorphic lenses and ultra-wide format screens for an immersive movie theater experience. It also features a new scaling mode that is optimized for the full native 4096 x 2160 (17 x 9) resolution of the D-ILA device.
The DLA-RS3000 is equipped with new "Installation Mode" that saves and recalls up to 10 different installation modes for different aspect ratios, lens presets, convergence and screen masking positions.
|Imaging Device||0.69 in D-ILA Device (4096 × 2160) ×3|
|8K e-shift Technology||Yes|
|Resolution||8192 x 4320 Precision via 8K e-shift technology|
|Lens||2X Motorized 100MM|
|Lens Shift||Motorized Shift±100% Vertical and ±43% Horizontal|
|Light Source||NSH 265W Lamp (lamp life: approx. 4500 hours when the lamp is in Low mode)|
|Contrast Ratio||Native: 100,000:1 | Dynamic: 1,000,000:1|
|Digital Video Signal||480p, 576p, 720p/50 Hz, 720p/60 Hz, 1080i/50 Hz, 1080i/60 Hz, 1080p/24 Hz, 1080p/50 Hz, 1080p/60 Hz, 3840x2160/24Hz, 3840x2160/25Hz, 3840x2160/30Hz, 3840x2160/50Hz*, 3840x2160/60Hz* 4096x2160/24Hz, 4096x2160/25Hz, 4096x2160/30Hz, 4096x2160/50Hz*, 4096x2160/60Hz*|
|Dimensions (WxHxD-inches)||19 5/8 x 9 1/4 x 20 3/8|
|Weight (net) (lbs)||48|
|HDMI||2 (Full Speed 18Gbps HDMI/HDCP 2.2 Compatible w/HDR)|
|3D Sync||1 (Mini DIN 3pin)|
|Trigger||1 (Mini jack, DC12V/100mA)|
|RS-232C||1 (D-sub 9pin)|
|Frame Packing||720p/50 Hz, 720p/60 Hz, 1080p/24 Hz|
|Side-by-Side||1080i/60 Hz, 1080p/60 Hz, 1080i/50 Hz, 1080p/50 Hz, 1080p/24 Hz, 720p/50 Hz, 720p/60 Hz|
|Top-and-Bottom||720p/50 Hz, 720p/60 Hz, 1080p/24 Hz|
|Product Weight (lbs.)||48|
|Viewable Screen Size (in.)||60" - 280"|
|Manufacturer Warranty||3 Year|
