General Specs |
| Product Weight (lbs.) | 77 |
| Depth (in.) | 28.3 |
| Width (in.) | 19.7 |
| Height (in.) | 8.46 |
| Lamp Life | 20000 |
| Manufacturer Warranty | 2 Year Parts & Labor |
General |
| Image Device | 3 D-ILA® devices (0.69 inches diagonal), 4096 x 2160, >90% Aperture Ratio |
| Brightness | 3000 ANSI Lumens (typical) - 2400 Lumens (minimum) |
| Display Resolution | 4096 x 2160 Pixels (8192x4320 addressable in e-shift mode) |
| Contrast Ratio | Greater than 12,000:1 (Sequential) |
| Uniformity | Greater than 78% |
| Color Management | 6-Axis adjustable CMS |
| Gamma Control | Std 2.2 Gamma and 3 user adjustable presets |
| Input - Supported Resolutions | 640x480, 800x600, 1280x720, 1024x768, 1366x768, 1280x800, 1440x900, 1280x1024, 1920x1080, 2048x1080, 1600x1200, 1920x1200, 2048x1536, 2560x1600, 3840x2160, 4096x2160 |
| Input Modes | 50Hz, 60Hz, 120Hz - Single, Dual, Quad Stripe or Quadrant Mode |
| Latency | 30ms@50Hz, 25ms@60Hz, 16.6ms@120Hz |
| Color Bit Depth | 12-bit Input, 12-bit Display |
| I/O Terminals | DisplayPort 1.2a x 4, LAN, RJ45 x 1, RS-232C, D-Sub 9 pin (male) x 1, Wired Remote (Mini) x 1, USB (for Service), Sync Out |
| Remote Control | RS-232C/LAN Fully featured control protocol - Wired/IR Remote Control |
| Power Requirement | AC 100V-240V, 50/60Hz (single phase) |
| Power Consumption | 750 Watts Maximum, 1.5W Standby |
| Noise Level | (0-26°C, 32- 40dB (A) at 39.4”/1m (3.3ft) |
| Operating Altitude | <6600ft (2000m) for safe operation |
| Installation Orientation | Any Orientation is supported - unlimited pitch and roll - motion compliant |
| Airflow Requirements | 106cfm (3m3) per minute minimum |
| Dimensions ( W x H x D ) | 19.7” x 8.46” x 28.3” (500 x 215 x 720mm) |
| Weight | 77lbs, (35kg) - Lens additional |
| Supplied Accessories | Power Cord x 2 (US, EU) *Instruction manual is available from the JVC site |
| Warranty | Two-Years Parts and Labor (per JVC Limited Warranty) |
Projection Lens (optional) |
| VSL2010 | .99:1 - Fixed Lens, ± 50% V, ± 10% H Offset |
| VSL2012 | 1.18:1 - Fixed Lens, ± 50% V, ± 10% H Offset |
| GLMZ-4009SZ | 0.94-1.3:1 - Zoom Lens, ± 50% V, ± 18% H Offset |
| GLMZ-4014SZ | 1.27-2.54:1 - Zoom Lens, ± 100% V, ± 40% H Offset |
Light Source |
| Blue Laser/Excited Phosphor - 20,000hrs to 50% output at full power | Yes |
| User adjustable, 125 steps, 100%-25% Power Level, Auto-Intensity function | Yes |
| 8-step Illumination System Aperture Control | Yes |
| Light Source Life | Average 20,000hrs to 50% output at 100% power setting |
Approvals |
| Safety | CSA C22.2 No.60950-1-07 /UL60950-1 2nd (NA) |
| Safety (Laser) | IEC60825-1 Ed2:Class 3R. (US) |
| EMI | FCC PART 15 SUBPART B, CLASS A (US) |
| Environmental | RoHS, Proposition 65 (US) |
