General Specs |
| Product Weight (lbs.) | 77 |
| Depth (in.) | 28.3 |
| Width (in.) | 19.7 |
| Height (in.) | 8.46 |
| Lamp Life | 20000 |
| Brightness | 3000 ANSI Lumens (typical) / 2400 ANSI Lumens (minimum) |
| Manufacturer Warranty | 2 Year Parts & Labor |
| Projector Brightness | 3000 |
General |
| Image Device | 0.69-inch D-ILA x 3 |
| Brightness | 3000 ANSI Lumens (typical) / 2400 ANSI Lumens (minimum) |
| Resolution | 4096 x 2160 |
| Contrast Ratio | 12,000:1 (typical) / 10,000:1(minimum) |
| Uniformity | Greater than 78% |
| Aperture | 8 Steps(Light Aperture) |
| Gamma Control | Std 2.2 Gamma and 3 User adjustable Gamma presets |
| Color Management | 6-Axis adjustable CMS |
| Input-Supported Formats | 640x480, 800x600, 1280x720, 1024x768, 1366x768, 1280x800, 1440x900, 1280x1024, 1920x1080, 2048x1080, 1600x1200, 1920x1200, 2048x1536, 2560x1600, 3840x2160, 4096x2160; 50Hz, 60Hz, 120Hz. Input: Single, Dual stripe, Quad stripe, Quad Cross input modes |
| Latency | 25ms w/60Hz, 30ms w/50Hz Input, 16.6ms w/120Hz Input(minimum) |
| Color Bit Depth | 12-bit Input, 12-bit display |
| I/O Terminals | Displayport 1.2a x 4; RS-232C, SYNC OUT, WIRED REMOTE IN, LAN, USB(for Service) |
| Remote Control | RS-232C/LAN Fully featured control protocol, Wired/IR Remote Control |
| Lens | GL-MZ4009SZ : 0.94~1.30 Short throw zoom lens, ± 50% Vertical Offset,, ± 18% Horizontal Offset Capability, GL-MZ4014SZ : 1.27~2.54 Standard throw zoom lens, ± 100% Vertical Offset, ± 40% Horizontal Offset Capability, VSL-2010 fixed lens 0.99:1, VSL-2012 fixed lens: 1.18:1 |
| Light Source | Blu-Escent Laser/Phosphor: 125 Steps Power Setting (25%-100%) |
| Light Source Life | 20,000H |
| NVG Capability | Yes |
| Power Requirement | AC 100V-240V, 50/60Hz |
| Power Consumption | 750 Watts, 51.5W Standby |
| Noise Level (0-26°C, 32-79°F) | <40dB (A) at 39.4”/1m (3.3ft) |
| Operating Environment | Temperature range: 5°C-35°C, Humidity: 20%-80% (non-condensing) |
| Operating Altitude | <2000 meters for safe operation |
| Installation Orientation | Angle free |
| Motion Platform | Motion compliant |
| Dimensions ( W x H x D ) | 19.7” x 8.46” x 28.3” (500 x 215 x 720mm) |
| Weight | 35kg |
| Supplied Accessories | Power Cord x2 (US, EU) |
| Optional Product | Calibration Software (PK-CS1601) |
Approvals |
| Safety | CSA C22.2 No.60950-1-07, UL60950-1, 2nd |
| Safety (for Laser) | North America: IEC60825-120072nd edition) |
| EMI | North America: FCC part 15 subpart B Class A(US) |
| Environmental | RoHS, North America Proposition 65 (US) |
