General Specs |
| Product Weight (lbs.) | 1.0000 |
| Number of Speakers | 5 |
PRO-500T-LS Specifications |
| Frequency Range | 130Hz - 30kHz +/- 3dB; 113Hz - 32kHz +/- 6dB; 93Hz - 36kHz +/- 10dB |
| High Frequency Driver | 1" (2.54cm) Aluminum Dome Tweeter mated to an all new 105º custom Tractrix® horn |
| Low Frequency Driver | 5" (12.7cm) IMG Woofer |
| Sensitivity | 88 dB |
| Coverage Angle | 105° |
| Power Handling | 60W Peak |
| Enclosure Material | UV Treated, Glass-Filled ABS Cabinet |
| Finish | Brown Matte, Paintable |
| Product Dimensions | 6.3” x 6.85” x 8.5” (160mm x 174mm x 216mm) |
| Product Weight | 5 lbs (2.27 kg) |
PRO-500T-LS 70V/100V Tap Settings |
| 70V | 3.75W, 7.5W, 15W, 30W |
| 100V | 7.5W , 15W, 30W |
| Bypass | 8 Ohms |
PRO-10SW-LS Specifications |
| Frequency Range | 47Hz - 103Hz +/- 3dB; 40Hz - 110Hz +/- 6dB; 33Hz - 123Hz +/- 10dB |
| System Type | Band Pass Half Burial |
| Woofer | 10" (25.4cm) IMG Dual Voice Coil |
| Sensitivity | 90 dB |
| Power Handling | 200W |
| Impedance | 70V @ 250W (Transformerless); 8 Ohm Stereo; 4 Ohm Mono |
| Product Dimensions | 21.85” x 16.10” x 16.10” (555mm x 409mm x 409mm) |
| Product Weight | 35 lbs (15.91 kg) |
PRO-10SW-LS Enclosure Material |
| Canopy | Rustproof, UV Resistant Aluminum |
| Cabinet | Heavy Duty, High Impact Polyethylene |
PRO-10SW-LS Finish |
| Canopy | Metallic Brown, Paintable |
| Cabinet | Matte Black, Paintable |
PRO-10-GS Specifications |
| Included in Box | 10” Ground Stake, 7” Security Plate, Installation Manual |
| Finish | Brown Matte, Paintable |
| Product Dimensions | 11.81” x 3.35” x 3.35” (300mm x 85mm x 85mm) |
| Product Weight | 2 lbs (0.91 kg) |
| Recommended for Use With | PRO-500T-LS 5” Landscape Satellite (PN: 1063137) |
PRO-10-GS Material |
| Ground Stake | Glass-Filled (25%) ABS |
| Security Plate | Galvanized Stamped Steel |
